Setting Out
Construction gridlines and detail set out exactly to the architect's drawing on site.
What Setting Out covers.
We translate the architect's design into physical reality on site — setting out gridlines, foundations, pile caps, drainage, structural steel and pool shells to sub-cm tolerances. We work from drawings produced in AutoCAD, Revit or ArchiCAD and issue as-built records when works complete, ready for the contractor's quality file.
- architecture
Sub-cm Tolerances
Gridlines, foundations, pile caps and drainage set out to sub-cm tolerances — verified against the architect's CAD model before any concrete is poured.
- construction
Site-Ready Coordination
We coordinate directly with the contractor's site team, holding weekly review meetings during the setting-out phase so nothing slips.
- schedule
As-Built Records
When works complete, we issue a full as-built record drawing suitable for the contractor's quality file and the council submission pack.
What you'll receive.
Deliverable 1
Coordinate schedule (CSV + DWG)
Deliverable 2
As-built record drawing
Deliverable 3
Setting-out report with tolerances
Deliverable 4
Re-mark-up visits as required
from MUR 50,000
Fixed-fee proposals returned within one working day. No obligation.
Request a QuoteReady to brief setting out?
Send us your drawings, address and access notes — we'll come back with a fixed-fee proposal within one working day.
Request This Service
